NTRACK OBD
Original price was: 7,000.00৳ .6,000.00৳ Current price is: 6,000.00৳ .
- Live tracking
- Vehicle Status
- Trip History
- 24/7 Call Support
- Geofence
- Basic GPS Report
- Disconnection alert
- High speed alert
- Daily summary SMS
Description
Specifications
|
MODULE
|
|
|---|---|
|
Name
|
Teltonika TM2500
|
|
Technology
|
GSM/GPRS/GNSS/BLUETOOTH
|
|
GNSS
|
|
|---|---|
|
GNSS
|
GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
|
|
Receiver
|
33 Channel
|
|
Tracking sensitivity
|
-165 dBM
|
|
Accuracy
|
< 2.5m CEP
|
|
Hot start
|
< 1 s
|
|
Warm start
|
< 25 s
|
|
Cold start
|
< 35 s
|
|
CELLULAR
|
|
|---|---|
|
Technology
|
GSM
|
|
2G bands
|
Quad-band 850 / 900 / 1800 / 1900 MHz
|
|
Data transfer
|
GPRS Multi-Slot Class 12(up to 240 kbps)
|
|
Data support
|
SMS (text/data)
|
|
POWER
|
|
|---|---|
|
Supply voltage range
|
10 – 30 V DC with overvoltage protection
|
|
Back-up battery
|
3.7 V 45 mAh
|
|
Power consumption
|
At 12V < 5 mA (Ultra Deep Sleep)
At 12V < 7 mA (Deep Sleep) At 12V < 7 mA (Online Sleep) At 12V < 8 mA (GPS Sleep) At 12V < 28 mA (nominal) |
|
BLUETOOTH
|
|
|---|---|
|
Specification
|
4.0 + LE
|
|
Supported peripherals
|
Temperature and Humidity sensor, Headset, Inateck Barcode Scanner, Universal BLE sensors support
|
|
INTERFACE
|
|
|---|---|
|
Connection
|
OBDII Socket
|
|
GNSS antenna
|
Internal High Gain
|
|
Cellular antenna
|
Internal High Gain
|
|
USB
|
2.0 Micro-USB
|
|
LED indication
|
2 status LED lights
|
|
SIM
|
Nano-SIM
|
|
Memory
|
128MB internal flash memory
|
|
PHYSICAL SPECIFICATION
|
|
|---|---|
|
Dimensions
|
52.6 x 29.1 x 26 mm (L x W x H)
|
|
OPERATING ENVIRONMENT
|
|
|---|---|
|
Operating temperature (without battery)
|
-40 °C to +85 °C
|
|
Storage temperature (without battery)
|
-40 °C to +85 °C
|
|
Operating humidity
|
5% to 95% non-condensing
|
|
Ingress Protection Rating
|
IP41
|
|
Battery charge temperature
|
+10 °C to +45 °C
|
|
Battery discharge temperature
|
-20 °C to +60 °C
|
|
Battery storage temperature
|
-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months |
|
Features
|
|
|---|---|
|
Sensors
|
Accelerometer
|
|
Scenarios
|
Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip
|
|
Sleep modes
|
GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
|
|
Configuration and firmware update
|
FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration)
|
|
SMS
|
Configuration, Eventsl, Debug
|
|
GPRS commands
|
Configuration, Debug
|
|
Time Synchronization
|
GNSS, NITZ, NTP
|
|
Fuel monitoring
|
GNSS Fuel counter
|
|
Ignition detection
|
Accelerometer, External Power Voltage
|
